APC Easy On-Line UPS 3000VA 230V with Intelligent Card Slot, LCD Display, USB & Serial Connectivity SRV3KRI

APC by Schneider Electric offers a new category of uninterruptible power supplies (UPS) for small and medium-sized enterprises that are designed to meet even the most unstable power situations. The APC Easy UPS On-Line is a flexible, high-quality, cost-competitive UPS designed to manage a wide voltage range and consistent power conditions and deliver quality that millions of IT professionals across the world rely on. Online double-conversion topology ensures a continually high quality of energy. Any disturbances on the distribution waveform are regenerated by converting AC to DC and then DC to AC with zero transfer time. The battery is only used as a backup power source. Pure sinewave output on the battery imitates utility power for maximum compatibility with active PFC (power factor corrected) servers and sensitive equipment. In good power conditions, the ECO operating mode bypasses unneeded electrical components to achieve high operating efficiency without losing protection, and high-efficiency rates stay consistent even at lower operating power levels. A USB connection enables you to utilise your PC to access extra power protection and management functions for your UPS via a USB Port, and the LCD interface delivers clear and accurate information in many languages with the opportunity to customise the UPS locally using simple navigation buttons. A SmartSlot permits customization of UPS capabilities with management cards, serial connectivity enables UPS control via a serial port and network manageability enables remote UPS power management via the network. Features: Over 7 minutes runtime at 70% load Online double-conversion, pure sinewave UPS battery backup 2U height rack-mount format (mounting kit sold separately) Easy-to-read LCD interface provides detailed & accurate UPS status information High operating efficiency in energy-saving ECO mode Intelligent temperature-compensated charging extends battery life Intelligent card slot enables remote UPS monitoring USB & serial connectivity Input: (1) IEC 60320 C20 Output: (6) IEC 60320 C13 (Battery Backup) + (1) IEC 60320 C19 (Battery Backup) 2-year repair or replace warranty Replacement battery: APCRBCV202 Specifications: Brand: APC Model: SRV1KRI Series: Easy Type: UPS Topology: Online Double-Conversion Rated power in W: 2400 W Rated power in VA: 3000 VA Output: Max Configurable Power (Watts): 2.4kWatts / 3.0kVA Efficiency at Full Load: 88.0 % Output Voltage Distortion: 3 % Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains Other Output Voltages: 220 V, 240 V Load Crest Factor: 3 : 1 Topology: Double conversion online Waveform type: Sine wave Bypass: Internal bypass (automatic and manual) Input: Input frequency: 40 – 70 Hz Auto sensing Input voltage range for main operations: 110 – 285 Half load, 160 – 280 Full loadV Number of Power Cords: 1 Efficiency at Full Load: 88.0 % Other Input Voltages: 220 V, 240 V Batteries & Runtime: Battery type: Lead-acid battery Typical recharge time: 4hour(s) Nominal Battery Voltage: 72 V Expected Battery Life (years): 3 – 5 Battery Charge Power (Watts): 60 Watts Communications & Management: Interface Port(s): DB-9 RS-232, USB Control panel: Multifunction LCD status and control console Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Available SmartSlot™ Interface Quantity: 1 Surge Protection and Filtering: Surge energy rating: 600Joules Environmental: Operating Temperature: 0 – 40 °C Operating Relative Humidity: 0 – 95 (Non-condensing) % Operating Elevation: 0 – 3000meters Storage Temperature: -20 – 50 °C Storage Relative Humidity: 0 – 95 (Non-condensing) % Storage Elevation: 0 – 15000meters Audible noise at 1 meter from surface of unit: 50.0dBA Online thermal dissipation: 910.0BTU/hr Protection Class: IP20 Physical: Dimensions (W x D x H): 437mm x 632mm x 86mm Weight: 27.6 kg (29kg)
