APC Easy UPS On-Line 15kVA/15kW Rackmount 9U 230V Intelligent Card Slot LCD W/RailKit SRV15KRILRK

This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 15kVA double-conversion on-line 9U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRV comes with hard wire 3-wire(1P+N+E) and 5-wire(3P+N+E) inputs, and 3-wire(1P+N+E) outlet. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The UPS and the built-in lead-acid battery has a 2-year warranty. Ideal for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication, and healthcare IT. Features: 15kVA/15kW double-conversion on-line pure sine wave 9U rackmount UPS High operating efficiency in energy-saving ECO mode Add up to 10 external battery packs (SRV120RLBP2-9A) for extended runtime Easy-to-read LCD interface for detailed and accurate information on UPS status Main Input Voltage: 230 V AC, 415 V AC Product or component type: Uninterruptible power supply (UPS) Other Input Voltage: 220 V, 230 V, 415 V Main Output Voltage: 230 V Other Output Voltage: 220 V, 240 V Rated power in W: 15000 W Rated power in VA: 15000 VA Output connector type: Hard wire 3-wire (1P + N + E) 1 Number of rack unit: 9U Range of product: Easy UPS On-Line Provided equipment: 1 USB cable 1 RS-232 configuration cable 3 rack mounting brackets 3 stabilization/wall mounting feet 6 jumper bar 2 external battery pack 1 battery cable user manual Batteries & Runtime Battery type: Lead-acid battery Battery voltage: +/- 120 V Number of battery filled slots: 0 Number of battery free slots: 0 Battery recharge time: 6 h Battery charger power: 2340 W rated Physical Colour: Black (RAL 7010) Height: 39.3 cm Width: 43.8 cm Depth: 69.0 cm Product weight: 157 kg Mounting location: Front Mounting preference: No preference Mounting mode: Rack-mounted USB compatible: Yes Mounting position: Horizontal Input Input voltage limits: 110...300 V half load, 176...300 V full load Number of input connectors: 1 hard wire 3-wire (1P + N + E), 1 hard wire 5-wire (3P + N + E) Network frequency: 40...70 Hz auto sensing Output Maximum configurable power in VA: 15000 VA Maximum configurable power in W: 15000 W Output frequency: 50/60 Hz +/- 3 Hz sync to mains Harmonic distortion: 2 % UPS type: Double conversion online Wave type: Sine wave Efficiency: 95 % (full load) Additional information: Configurable for 220 : 230 or 240 nominal output voltage Bypass type: Internal bypass (automatic and manual) Crest factor: 3 : 1 Environmental Ambient air temperature for operation: 0…40 °C Relative humidity: 0…95 % non-condensing Operating altitude: 0...3000 m Ambient air temperature for storage: -20…60 °C Storage Relative Humidity: 0…95 % non-condensing Storage altitude: 0…15000 m Acoustic level: 65 dBA Heat dissipation: 2503 Btu/h IP degree of protection: IP20
